Branick 7600 - Page 11

10
MODEL 7600
SERVICE PARTS
ITEM
PART NO.
QTY
DESCRIPTION
1
01-0085
2
POST
2
05-0130
3
LOWER HOOK KIT (Includes: Lower Hook, Hook Pad & Spring Pin)
3
05-0129
3
UPPER HOOK KIT (Includes: Upper Hook, Hook Pad & Spring Pin)
4
01-0263
1
BACK POST
5
03-0423
2
ADJUSTABLE HOOK HOUSING
6
03-0427
1
HOOK HOUSING
7
05-0131
2
UPPER RIGHT/REAR HOOK HOUSING KIT
(Includes: Hook Housing, (2) Nylon Bearings,
Knob, Spring, Lock Pin & Spring Pin)
8
05-0132
1
UPPER LEFT HOOK HOUSING KIT
(Includes: Hook Housing, (2) Nylon Bearings,
Knob, Spring, Lock Pin & Spring Pin)
9
05-0128
1
COMPRESSION HEAD KIT
(Includes: Compression Head, Shoulder Screw,
Nut & (3) Spring Pins)
10
10-0011
3
LOWER HOOK PAD
11
10-0012
3
UPPER HOOK PAD
12
10-0022
3
HANDLE GRIP
13
05-0136
3
LOCK PIN KIT (Includes: Knob, Spring & Lock Pin)
14
20-0043
1
THRUST BEARING
15
20-0044
6
NYLINER BEARING
16
21-0013
1
ACME DRIVE SCREW
17
05-0126
1
HUB & BEARING KIT
(Includes: Handle Hub, Threaded Hub, Thrust
Bearing, Thrust Washer & (3) Set Screws)
18
028-064
4
3/8-16 X 1 CARRIAGE BOLT
19
50-0025
1
5/16 X 1-1/2 SHOULDER SCREW
20
50-0065
1
3/8-16 X 3/4 HEX HEAD SERRATED FLANGE SCREW
21
50-0068
6
1/2-13 X 1-1/4 HEX HEAD SERRATED FLANGE SCREW
22
51-0015
2
ACME ADJUSTMENT NUT
23
53-0008
1
SPRING CLAMP
24
50-0189
3
1/4 – 20 x 1/2 SET SCREW
25
055-103
1
3/8-16 SERRATED HEX FLANGE NUT
26
055-154
4
3/8-16 NYLON HEX LOCK NUT
27
055-160
1
1/4-20 NYLON HEX LOCK NUT
28
061-042
6
3/16 X 3/8 SPRING PIN
29
061-091
3
1/4 X 7/8 SPRING PIN
30
05-0127
3
HANDLE KIT (Includes: Threaded Handle & Grip)
31
80-0400
1
INSTRUCTION DECAL
32
80-0398
1
MODEL 7600 DECAL
33
80-0399
1
7600 WARNING DECAL
* 34
81-0246
1
MODEL 7600 OPERATING INSTRUCTIONS
35
108-015
4
3/8 SAE FLAT WASHER
36
108-137
1
THRUST WASHER
* Item not shown
