Brano Industries pro-alpha 2000 - Section 2 Operator Terminology; Operator Components Overview

Electric
Motor
Motor
Capacitor
Rubber
Buffer
Base Plate
Lamp
Holder
"Opening" Sensor
Adjustor
"Closing" Sensor
Adjustor
Worm-shaft
Worm-shaft
Coupling
Wiring
Harness
Extrusion
Clamp
P.C. Board
P.C. Tray
"Power ON"
Indicator Light
Power
Socket
Terminal
Connector
-pro a
l
p
ha
2
0
00
LUBRICATION
DO NOT USE COMMON GREASE
USE ONLY "BRANO LUBRICANT GDO-L1" OR
"LOW-TEMP LUBRIPLATE" OR "AVGREASE 28"
Serial Number
299 A 8 / 3478
Worm-shaft
Aluminium Housing
( Extrusion )
Emergency Pull
"Release Cord"
Light Diffuser
Lens Cover
Service
Cover
Lubrication
Label
Serial No.
Label
Traveller
Hanger
Bracket
"Open" Limit
Switch Wire
( Brown )
"Closed" Limit
Switch Wire
( Purple )
"Open"
Limit Switch
( "Closed" Limit
Switch not shown )
o
r
0
p
h
a
p
al
2
0
-
0
LUBRICATION
DO NOT USE COMMON GREASE
USE ONLY "BRANO LUBRICANT GDO-L1" OR
"LOW-TEMP LUBRIPLATE" OR "AVGREASE 28"
Serial Number
299 A 8 / 3478
GENERAL DESCRIPTION
Electrically operated automatic garage door
operator for use on domestic type garage doors.
MAINFRAME AND COVERS
Galvanized steel frame supports the motor and
worm-screw housing. Moulded plastic cover
encloses motor and electronic control board.
WORM-SCREW AND ALUMINIUM HOUSING
One piece worm directly coupled to the motor.
O n e p i e c e a l u m i n i u m h o u s i n g .
ELECTRIC MOTOR
* Enclosed, fan-cooled, reversible type.
* "Sealed for Life" Ball Bearings.
* Single phase - 250 W - 50 Hz - 1450 rpm - 3,5 A
POWER SUPPLY
* 220 V - single phase - 50 Hz
LIGHT
* One lamp 100 W maximum output.
* Type BC - ( Bayonet base ).
* Automatic courtesy light timer +/- 3 minutes.
* Light can be switched "ON" from the wall
pushbutton.
"pro-alpha 2000”
OPERATOR TERMINOLOGY
SECTION 2
Fig No. 13
brano industries (pty ) ltd
Copyright C
1998 / 1999 / 2001
page 06
“brano” door operator installation manual"
i n d u s t r i e s
