figure 6).
figure 5
figure 6
4 Remove the bowl gasket from its seat (see
figure 7).
figure 7
5 Dismantle the faucet assembly (see figure
8).
figure 8
6 Slide the drip tray out and empty it.
5. 3. 2 CLEANING
1 Prepare at least two gallons of a mild
cleaning solution of warm (45-60 °C 120-140 °F)
potable water and dishwashing detergent. Do not
use abrasive detergent.
Important: if present, follow label directions, as
too strong a solution can cause parts damage,
while too mild a solution will not provide
adequate cleaning.
2 Using a brush, suitable for the purpose,
thoroughly clean all disassembled parts in the
ATTENTION
Before any disassembly and/or cleaning
procedure make sure that the dispenser is
disconnected from its power source.
IMPORTANT
Do not attempt to wash any machine
components in a dishwasher.
IMPORTANT
In order to prevent any damages to the
dispenser use only a detergent suitable
with plastic parts.
