Braun BP 6100 Instructions

8
9
6. LCD Display will show the results and WHO indicator arrow after measurement.
After taking blood pressure measurement, turn o the device by pressing the start button
(1) or
automatically after 1 minute.
Memory function
Your blood pressure monitor can store the latest 40 readings for both users each for the BP6000, 50
readings for both users each for the BP6100 and 60 readings for both users each for the BP6200.
Storing measurement data
After each blood pressure measurement, the Systolic pressure, diastolic pressure, pulse rate and the
time & date of specic day will be automatically stored. Memory #01 is always the most recent one.
Once the memory is full, the oldest values will be overwritten.
Press memory button
M
(2) to review the stored data. The last memory data (sys/dia/pul) with
measurement date/time, IHB (for BP6200 only) and WHO indicator will show on LCD. Press memory
button
M
(2) again to show the previous data. Be aware that the correct user A or B is chosen.
Average function for BP6000
Press the average button (5) to show last 3 readings average
on LCD. Press average button again to clear LCD for 0.5 seconds,
then results will be shown again.
Average function for BP6100
Press the average button (5) to show the full day average of
past 7 days on LCD. Press average button again to clear LCD for 0.5
seconds, then results will be shown again.
Average function for BP6200
Press the average button (5) to show the full day average of past 7 days on LCD.
Press the average button second to show the morning average of past 7 days on LCD.
If the result is with morning hypertension, the morning hypertension icon will
be shown. Press the average button third time to show the evening average of past
7 days on LCD. Press the average button fourth time to show the full day average of
past 7 days again.
A A
A
P
MD
A
Select mode
How to select user A /user B
• Make sure the Product is in power o mode.
• Slide the user switch to user A or user B, the current user mode will ash on the LCD display.
The WHO/ESH indicator to evaluate blood pressure data
This device has a blood pressure level indicator established according to WHO
and the European Hypertension Society Guidelines (ESH) in 2007. For every
measurement displayed on the screen, the cursor will indicate the blood pressure
level with the corresponding color code, from green to red. You can use this
classication daily to guide you to understand your blood pressure level. If you are
really concerned by the classication level, you should consult your doctor.
Setting month, date and time
a. Switch o the device for the date/time setting.
b. User press set button
(4) to start the year setting, then the
“year” will blink display, user can press adjust (3) to adjust
year by increase step “1”.
c. User press set button
(4) to start the month setting, then
the “month” will blink display, user can press adjust (3) to
adjust month by increase step “1”.
d. User press set button
(4) to start the day setting, then the
“day” will blink display, user can press adjust (3) to adjust
day by increase step “1”.
e. User press set button
(4) to start the hour setting, then the
“hour” will blink display, user can press adjust (3) to adjust
hour by increase step “1”.
f. User press set button
(4) to start the minute setting, then
the “minute” will blink display, user can press adjust (3) to
adjust minute by increase step “1”.
g. User press set button
(4) to end all the date/time setting,
all the blink are stopped.
Note: Holding the adjust button will scroll the value.
Taking a measurement
Wrap the cu around the arm (see “applying the arm cu” section above).
1. Sit upright on the chair to have a correct posture.
2. Press and release start button
(1), date/time and current user will be displayed.
3. Set user A/B switch (6) to A for user A or B for user B, LCD display will show user A or B symbol.
4. Press and release the start button
(1), all icons on display will be shown for 2 seconds. The
device will adjust to zero automatically. The measuring blood pressure symbol will then ash on
the display and the air pressure will automatically pump up to certain pressure level and start
measurement.
Do not move or talk in the midst of taking blood pressure measurement.
5. After the air pressure has increased, the pulse is detected, the heart rate symbol
will start
ashing.
RED >
GREEN >
A
B
A
P
MD
A
B
A
P
MD
A
P
MD
b.
A
P
MD
c.
A
P
MD
d.
A
P
MD
e.
A
P
MD
f.
