18
GB
SU-WL450
1 Attach Wall-Mount Attachment (supplied with the TV) to the rear of the TV (to make it
parallel with the wall).
Note
• If using an electric screwdriver, set the torque at approximately 1.5 N·m {15 kgf·cm}.
• Be sure to fasten the Wall-Mount Attachment when attaching them to the TV.
Use only a flat head screwdriver to install the Wall-Mount Attachment. Use of another tool might result in over
torqueing the Wall-Mount Attachment and damaging the TV.
2 Make sure that the wall has enough space for the TV and is capable of supporting a
weight of at least four times that of the TV. Refer to the following table on installing the TV
to the wall. See page 22-24 (Specifications) for the TV’s weight.
Soft cloth
1.5 N∙m
{15 kgf∙cm}
Screen centre point
80
Standard mounting Slim mounting
To Next Page
