20
GB
4 Connect necessary cables to the TV.
Note
• You cannot access to any terminal after installing the TV to the wall.
5 Install the TV to the Base. Refer to “5” of Installation Guide and “Installing the TV to the
Wall” of Operating Instructions supplied with the Wall-Mount Bracket.
Refer to the instructions supplied with the Wall-Mount Bracket for your model to install the TV on the wall.
Model Name KDL- Hook location
55W800C/
50W800C/
43W800C
a
Screw (+PSW 6 x 20)
Belt
Spacer (20mm)
Soft cloth
Screw (+PSW 6 x 20)
Pulley
To Next Page
