Pneumatic Actuators
Installation : 3
$OOLQIRUPDWLRQKHUHLQLVSURSULHWDU\DQGFRQÀGHQWLDODQGPD\QRWEHFRSLHGRUUHSURGXFHGZLWKRXWWKHH[SUHVVHGZULWWHQFRQVHQWRI%5$<,17(51$7,21$/,QF
7KHWHFKQLFDOGDWDKHUHLQLVIRUJHQHUDOLQIRUPDWLRQRQO\3URGXFWVXLWDELOLW\VKRXOGEHEDVHGVROHO\XSRQFXVWRPHU·VGHWDLOHGNQRZOHGJHDQGH[SHULHQFHZLWKWKHLUDSSOLFDWLRQ
Installation : 3
Actuator Installation Notes
These notes apply to the installation of Bray S92/93 pneumatic valve actuators.
 Verify that the valve and the actuator are both in the same
position (both open or both closed) before mounting the
actuator to the valve.
 Apply a light coating of grease to the inside of the actuator
output bore before installing the actuator on the valve. This
will allow the actuator to be more easily removed from the
valve stem even after years of service.
 ,IVWHPDGDSWHUVDUHUHTXLUHGWRPDWFKWKHDFWXDWRURXWSXW
bore to the valve stem, apply a light coating of grease to
the inside of the stem adapter as well as the inside of the
actuator output bore.
 Some stem adapters are kits consisting of multiple
components. These kits may contain spacers that look
like stem adapters, but are designed to keep the stem
adapter in place during operation of the actuator. Verify
that all stem adapters and spacers are installed in the
SURSHUSRVLWLRQDQGVHTXHQFH
 ,INH\HGVWHPDGDSWHUVDUHXVHGWKHNH\PXVWEHKHOGLQ
the keyway so that it will not work loose during operation
of the actuator. The key may be retained by any one of
several methods:
,I WKH YDOYH VWHP KHLJKW PDWFKHV WKH GHSWK RI WKH
DFWXDWRU RXWSXW ERUH XVH D NH\ WKDW ÀWV WKH IXOO OHQJWK
of the keyway. Tack weld the key to the adapter before
installation in the actuator.
Upset the end of the keyway after the key has been
installed in the shaft by using a punch or chisel.
 ,I PRXQWLQJ VWXGV DUH XVHG LQVWHDG RI EROWV WKUHDG WKH
studs completely into the actuator before placing the
actuator on the valve. This assures that the full strength of
the connection is achieved.
 :KLOH WKH PRXQWLQJ EROWV DUH RQO\ ÀQJHU WLJKW F\FOH
the actuator fully open and fully closed to verify proper
alignment on the valve.
 Tighten the mounting bolts or nuts in a diagonal pattern to
evenly distribute stress in the bolts.
Actuator Mounting Codes for S92/93 - Imperial (In)
Actuator
Sizes
Valve
Code
Inner Bolt Circle Outer Bolt Circle Stem Hole
Bolt Circle
(+/- .005)
No.
Holes
Bolt Size
Bolt Circle
(+/- .005)
No.
Holes
Bolt Size
Bore
Diameter
(+/- .004)
Across
Flats
(+ .002-.0)
Depth
Keyway Width
(+ .002-.0)
48 AA 1.42 4 #10-32 1.97 4 1/4-20 0.4 0.32 1.3 NA
63 A 1.969 4 1/4-20 2.756 4 5/16-18 0.552 0.395 1.38 NA
83 C 1.969 4 1/4-20 2.756 4 5/16-18 0.749 0.513 1.46 NA
93 C 1.969 4 1/4-20 2.756 4 5/16-18 0.749 0.513 1.46 NA
119 E 2.756 4 5/16-18 4.921 4 1/2-13 1.182 0.867 2.2 NA
128 E 2.756 4 5/16-18 4.921 4 1/2-13 1.182 0.867 2.2 NA
160A E NA NA NA 4.921 4 1/2-13 1.182 0.867 2.2 NA
160B F NA NA NA 4.921 4 1/2-13 1.38 NA 2.38 0.394
210 G 4.921 4 1/2-13 6.496 4 5/8-11 1.97 NA 2.76 0.472
255A H 6.496 4 5/8-11 4.724 X 7.874 4 5/8-11 2.505 NA 4.25 0.625
255B K 6.496 4 5/8-11 4.724 X 7.874 4 5/8-11 3.006 NA 4.25 0.750
Actuator Mounting Codes for S92/93 - Metric (mm)
Actuator
Sizes
Valve
Code
Inner Bolt Circle Outer Bolt Circle Stem Hole
Bolt Circle
(+/- .127)
No.
Holes
Bolt Size
Bolt Circle
(+/- .127)
No.
Holes
Bolt Size
Bore Dia.
(+/-.102)
Across Flats
(+ .050-.0)
Depth
Keyway
Width
48 AA 36 4 M5 x 0.8P 50 4 M6 x 1.0P 10 8 33 NA
63 A 50 4 M6 x 1.0P 70 4 M8 x 1.25P 14 10 35 NA
83 C 50 4 M6 x 1.0P 70 4 M8 x 1.25P 19 13 37 NA
93 C 50 4 M6 x 1.0P 70 4 M8 x 1.25P 19 13 37 NA
119 E 70 4 M8 x 1.25P 125 4 M12 x 1.75P 30 22 56 NA
128 E 70 4 M8 x 1.25P 125 4 M12 x 1.75P 30 22 56 NA
160A E NA NA NA 125 4 M12 x 1.75P 30 22 56 NA
160B F NA NA NA 125 4 M12 x 1.75P 35 NA 60 10
210 G 125 4 M12 x 1.75-6H 165 4 M20 x 2.5P 50 NA 70 12
255A H 165 4 M20 x 2.5P 120 x 200 4 M20 x 2.5P 64 NA 108 16
255B K 165 4 M20 x 2.5P 120 x 200 4 M20 x 2.5P 76 NA 108 19
Refer to Series 92/93
Operations and Technical Manual OM-92_93-001 01-2013
