TRIAD SERIES 3-PIECE BALL VALVE
Installation, Operation, and Maintenance Manual
of © BRAY INTERNATIONAL INC ALL RIGHTS RESERVED BRAYCOM The Information
contained herein shall not be copied transferred conveyed or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International Inc
GENERAL INFORMATION
Introduction
NOTICE
Failure to follow these procedures and observe these notes
cautions and warnings including the use of non-OEM parts
could lead to hazards andor void product warranties either
expressed or implied
The design features of this valve include a three piece
construction allowing ease of maintenance without special tools
These valves feature a “free floating” ball The ball is not fixed
but is free to move with the line pressure As a result of this
feature these valves are capable of tight shut-o with flow in
either direction regardless of the position of the valve in the line
The downstream seat opposite the pressurized side of a closed
valve must carry the load exerted by the line pressure on the ball
while the upstream seat is subject to little load or wear Turning
the valve end-for-end in the pipeline will increase useful seat life
by dividing seat wear between the two seats
The valve should be maintained as part of a preventative
maintenance program and in accordance with Bray’s
recommended pressure and temperature to ensure a long service
life During shipment storage and in operation the valve should
be fully open or fully closed (“open” is preferred for shipping and
storage)
Additional product information (such as application data
engineering specifications actuator selection etc) is available
from your local Bray distributor or sales representative or online
at BRAYCOM
For complete details on the latest product certifications
visit BRAYCOMCertifications
Use
The following instructions are designed to assist in the unpacking
installation and maintenance as required for Bray ball valves
Product users and maintenance personnel should thoroughly
review this manual prior to installing operating or performing any
maintenance In most cases Bray valves actuators and accessories
are designed for specific applications (eg with regard to medium
pressure and temperature) For this reason they should not be used
in other applications without first contacting the manufacturer
WARNING
Before installing the equipment confirm that it is suitable
for the intended service The identification tags describe the
maximum allowable service conditions for this product Be
sure that the installation is protected by appropriate pressure
control and safety devices to ensure that acceptable limits are
not exceeded
