Series 70 Electric Actuator
Installation, Operation and Maintenance Manual
R
1
9
7
8
6
21
20
19
13
16
18
17
15
14
12
11
10
4
3
2
13
14
5
SERIES 70, SIZE -180
3: 1 GEAR BOX EXPLODED VIEW
ITEM NO.
DESCRIPTION
1 FASTENING SCREW
2
POSITION INDICATOR PLATE
3
POSITION INDICATOR GASKET
4
ACTUATOR/GEAR BOX GASKET
5 DOWEL PIN
6 O-RING
7 WASHER,FLAT,NYLON
8 NUT,HEX
9 BOLT,HEX HD
10 COVER
11 WASHER, CONICAL
12
ACTUATOR/GEAR BOX FASTENING SCREW
13 OUTPUT GEAR BEARING
14
IDLER/INPUT GEAR BEARING
15 COVER GASKET
16 INPUT GEAR
17 OUTPUT GEAR
18 IDLER GEAR
19 COVER
20 LOCK WASHER
21
BASE FASTENING SCREW
BUSA
BUSA Steven Ospina
10/21/2013
1
Series 70 – Size 130, 180 – 3:1 Gear Box Exploded View
