week for the starting point (see previous sec-
tion). Now press the SET button (5) until the hour
display starts fl ashing and press the UP button (4)
to set the hours for the starting point. Repeat this
procedure for the minute display. Finally press the
SET button (5) to fi nish price 1 settings.
Set Cost/kWh (Price 2)
Setting the cost/kWh for price 2 is similar to price 1.
Ensure that at the beginning price 2 (18) is dis-
played.
Press the FUNC button (6) to toggle the display
to show price 2 (18) before starting the setting
procedure with the SET button (5).
Display Metering Functions
Repeatedly press the FUNC button (6) to cycle
through the following information: VOLTAGE,
AMP, WATT – kWh - TOTAL PRICE (10, 18).
Press the FUNC button (6) to display the current
draw of the connected appliance in the value fi eld
(10) on the LCD, AMP (11) is displayed in the unit
section and the POWER FACTOR (27, 28).
Press the FUNC button (6) again to display the
wattage of the connected appliance in the value
fi eld (10) on the LCD, WATT (12) is displayed in
the unit section and the POWER FACTOR (27,
28).
Press the FUNC button (6) again to display the
power consumption of the connected appliance
in the value fi eld (10) on the LCD. kWh (13) is
displayed in the unit section and the POWER
FACTOR (27, 28).
Press the FUNC button (6) again to display the
TOTAL PRICE (10, 18) and the TOTAL ON TIME
(21, 22, 24) in minutes of the connected appli-
ance.
Press the FUNC button (6) again to display the
VOLTac. (15) and the Hz (26, 27). Hold the FUNC
button (6) at least 2 seconds to display COST/
kWh.
If the total load is exceeded MAX OVERLOAD
WARNING (17) will fl ash on the display (2).
5.4.3 Standby Mode
The display (2) returns approx. 10 seconds after
pressing the buttons to standby mode and shows
the current time (20, 21, 22, 23, 25), day of the
week (19), line voltage (10, 15) and frequency (26,
27).
5.4.4 Reset Button
Press the reset button RESET with a pointed
object to clear all data in the memory including the
current time and all programs. For a few seconds
the complete display (2) with all parameters is
shown.
5.4.5 Change Batteries
The power meter comes ex factory with 3 x 1.5 V
LR44/AG13 button cells installed in the battery
compartment. To exchange the batteries, please
follow these steps:
The battery compartment is located at the rear of
the unit. Use a fl at screwdriver to carefully lift the
cover of the battery compartment. Remove the
empty batteries and replace them with new ones.
Observe the polarity (+/-) as indicated inside the
cover (fl at side (+) to the left). Carefully replace
the cover again. Take care not to damage the
terminals when closing the cover.
The cover must be replaced before use.
During longer periods of non-use remove the
batteries from the power meter to avoid battery
leakage. Leaking batteries can cause electric
shock and damage to the power meter.
Only change batteries if the power meter is dis-
connected from mains power supply. Only replace
batteries with same type. Do not mix new and
empty batteries.
Do not dispose off batteries with the household
waste. Return empty batteries to the respective
collection points.
6. Maintenance and Care
This product is maintenance-free. Never open or
disassemble the product. Before cleaning discon-
nect the power meter from the wall outlet and the
appliance.
Clean the exterior only with a clean and soft cloth.
7. Disposal
The power meter should not be disposed
of in the regular household waste at the
end of its operational lifetime. It must be
taken to a collection site for the process-
ing of electric and electronic devices for
disposal.
Consult your town or city offi ce for
options for environmentally sound and
proper disposal of this product.
8. Declaration of Conformity
The Declaration of Conformity is fi led with the
manufacturer. Technical modifi cations reserved.
9. Manufacturer
Hugo Brennenstuhl GmbH & Co. KG
Seestraße 1-3 ∙ D-72074 Tübingen
For further information we recommend Service/
FAQ on our web-site www.brennenstuhl.com.
Hugo Brennenstuhl GmbH & Co. KG
Seestraße 1-3 ∙ D-72074 Tübingen
www.brennenstuhl.com
0454555/0616
