brewer access high-low - Advanced Troubleshooting (Step 7.1); Powered Backrest and Return-to-Chair Function; Movement Control and Seat Lowering Issues; Backrest Actuator and Wiring Harness

To Previous Page

Call Brewer Tech Support 888-Brewer-1.

Does table have a powered backrest?

Yes No

Are there other problems not yet

resolved?

Yes No

Replace foot control. Is problem xed?

Yes No

Does seat begin to lower before backrest

has raised to the point where the backrest

clears the rear cabinet?

Yes No

Step 7.1 continue here

Step #

7.1

Does table return to chair position

when blue button is pressed on foot

control?

No Yes

Does the backrest raise but the seat

will not lower when return to chair blue

button is pressed on foot control?

Yes No

Is there no movement at all, or is

movement not stopped by stop button

or foot control pedals?

No Yes

The backrest actuator return chair

that protrudes from the center of the

back of the seat section is defective

or its wiring harness (blue and red

wires) is damaged or disconnected?

With backrest raised check for closed

circuit at the blue and red wired Molex

connector. Reconnect wiring harness

or replace defective switch. Is problem

xed?

No Yes

The backrest actuator return chair

that protrudes from the center of the

back of the seat section is defective

or its wiring harness (blue and red

wires) is damaged or disconnected?

With backrest raised check for closed

circuit at the blue and red wired Molex

connector. Reconnect wiring harness

or replace defective switch. Is problem

xed?

Yes No

Return to step 1

6000 SERIES TABLE TROUBLESHOOTING CHART (continued)
