Page #101 background imageLoading...
Page #101 background image
101
RUDOLF - Ref. : CDR 27 028_gb
R-DPA96 A/AN - R-MODULE 3 (RS485 - JBUS/MODBUS
®)
COMMUNICATION
LAST 10 ALARMS EVENT LOG (FUNCTION 3)
Alarm n-3
Alarm n-4
Decimal Hexa. Number Text Unit
address address of words
22 : V1
23 : V2
24 : V3
25 : thd In
26 : thd V1
27 : thd V2
28 : thd V3
29 : ΣP-
30 : ΣQ-
31 : ΣPFC
3121 C31 2 Upper threshold value
3123 C33 1 Duration s
3124 C34 1 Day
3125 C35 1 Month
3126 C36 1 Year
3127 C37 1 Hour
3128 C38 1 Minute
3129 C39 1 Second
Decimal Hexa. Number Text Unit
address address of words
3130 C3A 1 Output number (1 to 6)
3131 C3B 1 Lower threshold :
0 : no alarm
1 : I1
2 : I2
3 : I3
4 : In
5 : U12
6 : U23
7 : U31
8 : ΣP+
9 : ΣQ+
10 : ΣS
11 : F
12 : ΣPFL
15 : thd I1
16 : thd I2
17 : thd I3
18 : thd U12
19 : thd U23
20 : thd U31
21 : HOUR
22 : V1
23 : V2
24 : V3
25 : thd In
26 : thd V1
27 : thd V2
28 : thd V3
29 : ΣP-
30 : ΣQ-
31 : ΣPFC
