2022 Owner’s Manual Eagle 8 BRIG ltd
9
TECHNICAL SPECIFICATIONS
.
Model name
Eagle 8
Design Categories according to Directive 2013/53/EU B or C
Length (without engine) 7.98 m
Beam 2.90 m
Height (without / with T-Top) 2.20 / 2.78 m
Inflatable tube diameter, max. 0.58 m
Cockpit dimensions ( length X width ) 6.0 x 1.70 m
Deadrise on transom / in middle section 20° / 22°
Transom height 630 mm
Number of separate inflatable buoyancy chambers 5
Nominal pressure for each inflatable buoyancy chambers 0.2 bar (2.9psi)
Maximum number of persons (75kg each) B/C design category 11 / 16
Engine:
Recommended engine power 300HP (224kW)
Maximum engine power 350HP (262kW)
Maximum engine weight (including controls and batteries) 410 kg
Engine shaft length (inches) Extra long / 25”
Weight parameters:
Weight of empty boat (with steering console, with seats, without engine,
without fuel)
1140 kg
Weight of boat with max equipment from manufacturer without engine 1260 kg
Displacement in Light Craft Condition (LCC) 1635 kg
Maximum total load (ML) (total weight of the liquids
in tanks, weight of
the persons and cargo onboard)
1695 kg
Maximum recommended load (including mass of the persons and cargo
onboard, but excluding mass of the max motor, the mass of the contents
of fixed fuel, water tanks when full) (builder’s plate)
1345 kg
Loaded displacement mass (LDC) 3330 kg
