M10x30
M10x30
M10x30
M10x30
M14x100
M14x100
M12x90
Existing bolt Attach with 50Nm
ø11x35x3
ø11x35x3
L=60mm
L=60mm
M6x20
Self-locking
Existing bolt Attach with 50Nm
9535286
9531242
9520079
4399/5
4399/4L
4399/4R
© 439970/16-12-2008/2
