B+/30: PIN 1 or PIN 14
GN
RD
B+/30: PIN 1 + PIN 14
2x B+/30: PIN 1 + PIN 14
/31: PIN 21
GN
RD
ON
L
O
C
K
Ignition ON
Diagnosis function of control LEDs
GN
GN
B+/30
< 10,8 V
RD
RD
Lamp substitution if the trailer indicators fail
If the indicator is activated, the corresponding
rear lamp on the trailer becomes the indicator
( lamp substitution):
If an indicator fails the left or right rear light
compensates the faulty indicator by flashing
at the correct frequency!
