1008577ALL-E
==================================================================================================
English Manual
4
21
the notch in the foot pedal oriented
towards the raised tongue on
the drawbar.
See illustration.
4
21
ASSEMBLY
4
21
Starred edge of the waSher needS to be facing the Spring.
15
21
4
1615
NOTE: Foot pedal can be adjusted slightly while installing
bolt (15). This will help to align the bolt with the hole on the
other side of the drawbar.
Assembly Step 3-B
4
21
16
15
16
Assembly Step 3-A
