10
H. Upon loading the film, rotate the film-winding crank until it stops
to place the first frame into place for taking the picture. The expo-
sure counter will also change from "S" to "1", while the shutter will
also be cocked.
When the film back is detached from the main camera body for film
loading, the manual film winder is used for advancing the film. The
film will stop when it is in place for the first exposure, with the expo-
sure counter also changing to "1". However, it will be possible to
rotate the manual film winder and it should be rotated two or three
times more, in order to take up any slack in the loaded film.
* When loading 220 roll film in the Film Back SQ 220, do not mistake
the dotted line before the arrow-mark for the start-mark.
To set the film sensitivity of the film loaded in the film back, revolve
the ASA/ISO film speed dial with a slight lifting action, as illustrated,
and set the film speed scale to the index. There are click-stops at
1/3rd increments, in this case. (The dial can be revolved in either
direction.)
* The ASA/ISO film speed dial is automatically coupled to the finder
with built-in exposure meter, when attached.
5. Film Loading (con’t)
6. ASA/ISO Film Speed Dial
