15
A. The finder can be interchanged, with other optional finders, to
match shooting conditions to photographic conditions. To attach the
finder, align the front end of the finder with the front end of the find-
er frame on top of the main camera body, as shown. Then, gently
lower the finder and, when well seated, slide forward until it locks.
B. To detach, simply depress the finder release button, while, at the
same time, sliding the finder backwards where it can be taken up.
A. The focusing hood of the waist-level finder is opened by pushing
up on the focusing hood catch at the rear end of the folded waist-
level finder.
* There is no standard finder for the Bronica SQ-A, with the user hav-
ing a choice of several finders. Instructions are based on the waist-
level finder because of its popularity.
B. The magnifier is flipped into viewing position by simply sliding the
release lever in the arrow-indicated direction. To store the magnifier,
simply push it down until it catches.
* The magnifier can be exchanged for one matching the eyesight of
the user.
C. To close the focusing hood, first, push down the magnifier (if it is in
viewing position). Next, press in both side frames, as illustrated, and at
the same time, press the front frame back towards the rear. The
focusing hood will automatically be folded down.
15. Interchanging Finders
16. Waist-Level Finder and Interchanging Magnifiers
