WALL MOUNTING (OPTIONAL)
IMPORTANT: Care should be taken to ensure that there are no dangerous
objects hidden beneath the wall surface (e.g.; electrical wires, pipes, etc.).
Remove rubber feet prior to screwing the bracket to the wall.
1. Remove all rubber feet from under the base.
2. Remove the cover of the base and mark the drill hole positions (see above).
3. Use a 5mm drill to drill the holes and then insert the anchors.
4. Insert the ring handle and plug in the adapter jack.
5. Screw the bracket onto the wall.
6. Install the base cover.
Base Cover
Mark drill hole positions
through these holes.
