Name: Brother DCP-L5500D
Brand: Brother
Rating: 5 (1 reviews)

To Next Page

To Previous Page

3-14

Confidential

ADF unit

Harness colors are subject to change for some reason.

ADF motor harness

(RD)

ADF FG harness

(RD or OR)

ADF cover harness (BK, WH)

Document detection sensor harness (WH)

Document scanning position sensor harness (BL)

Second side CIS flat cable
