Brother DCP-L5600DN Service Manual

2-25
Confidential
Media Type
Mismatch
Reload correct paper
in MP Tray, then press
[Retry].
When printing from the MP tray,
paper type setting in the machine
does not match the setting in the
driver.
9201 2-68
Reload correct paper
in Tray1, then press
[Retry].
When printing from the paper tray
1, paper type setting in the
machine does not match the
setting in the driver.
9202 2-68
Reload correct paper
in Tray2, then press
[Retry].
When printing from the paper tray
2, paper type setting in the
machine does not match the
setting in the driver.
9203 2-68
Reload correct paper
in Tray3, then press
[Retry].
When printing from the paper tray
3, paper type setting in the
machine does not match the
setting in the driver.
9204 2-68
Reload correct paper
in Tray4, then press
[Retry].
When printing from the paper tray
4, paper type setting in the
machine does not match the
setting in the driver.
9205 2-68
Reload correct paper
in Tray5, then press
[Retry].
When printing from the paper tray
5, paper type setting in the
machine does not match the
setting in the driver.
9206 2-68
No Drum Unit Open the Front Cover,
then install the Drum
Unit.
Detected that the drum unit was
not set by detecting the GRID
terminal current.
6200 2-48
No HUB Support No HUB Support. A USB device with a built-in hub is
connected.
--- 4.14.3
Error message
Description
Error
codes
Refer
to:
First line Second line

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
