Brother EF4-N21 - Page 22

EF4-N11, V41A, N21, V51A, MA4-N31, V61A 22/31
2001.9
Gauge parts list
[Models EF4-N21, V51A]
Heavy materials
Application
Mock−safety
(Tractor type)
Ruffling
Ruffling
(mock-safety)
Sub-class
H=High-lift
E=Extra high-lift
31
−6 E
−7 E
32
−6 E
−7 E
31
−6 (B) E
−7 (B) E
33
−5 H
34
−5 H
(mm)
Needle gauge
32.2
1. Needle
151474−018 151474−011
2. Presser foot assy
(Stitch tongue)
S29871−001(6)
(S19286-001)
S29869−001(7)
(S19975-001)
S30898−001
(S30900-001)
S19291−001
S20402−001 S20398−001
3.
Needle clamp assy
S24663−001 (6)
S24664−001 (7)
S19162−001
4. Needle plate
S21392-001
(S21393-001)
(S21394-001)
J
S19500−001
(S19218-001)
(S19201-001)
A
5.
Main feed dog assy
(Main Feed dog)
(Chain feed dog)
S21395−001 S19243−001
6.
Differential feed dog
Angle knife
S20898-101
Upper knife
144074−350
7. Upper knife
Angle knife
S20583−001
8. Lower knife
S20582−001
T = 1.5
9. Over looper
S20438−001
G
S20442−001
R
S20438−101
G
S20424−001
B
S20436−001
F
