Brother EF4-N21 - Page 25

EF4-N11, V41A, N21, V51A, MA4-N31, V61A 25/31
2001.9
Gauge parts list
[Models MA4-N31, V61A]
Thin Thin  Medium
Application
5 Threads 4 Threads (For small type) 5 Threads 4 Threads (For small type)
Sub-class
S=Standard
H=High-lift
E=Extra high-lift
61
−2 S
−3 S
−4 S
−5 S
62
−2 S
−3 S
−4 S
−5 S
61
−3 (B)
−4 (B)
−5 (B)
63
−3 S
−4 S
−5 S
−6 H
−7 H
64
−3 S
−4 S
−5 S
−6 H
−7 H
63
−3 (C)
−4 (C)
−5 (C)
(mm)
Needle gauge
23
1. Needle (Q’ty)
151474−011 (2) 151474−014 (2)
2. Presser foot assy
(Presser foot .F)
S19304−101
(S19312-001)
S30586-001 (3,4)
Stitch tongue
S30588-001
S30592-001 (5)
Stitch tongue
S30593-001
S19313−201
(S30971-001)
S30594-001 (3,4)
Stitch tongue
S30588-001
S30597-001 (5)
Stitch tongue
S30593-001
S29146−001 S20404−001
3.
Needle clamp assy
S25194−001 (2)
S25195−001 (3)
S19174−001 (4)
S19175−001 (5)
S20234−001 (3)
S20235−001 (4)
S20236−001 (5)
S35651−001 (6)
S25196−001 (7)
S19176−001 (3)
S19177−001 (4)
S19178−001 (5)
4. Needle plate
S19221−201
(S19222-201)
(S33172-001)
L
S20241−101
(S20242-101)
(S20243-101)
H
S19221−201
(S19222-201)
(S33172-001)
L
5.
Main feed dog assy
(Main Feed dog)
(Chain feed dog)
S19245−001 S20245−001 S19245−001
6.
Differential feed dog
144074−350
7. Upper knife
8. Lower knife
S20899−001 (2)
T = 1.0
S20582−001 (3,4,5)
T = 1.5
S20899−001 (3)
S20582−001
(4,5,6,7)
T = 1.5
S20899−001 (2)
T = 1.0
S20582−001 (3,4,5)
T = 1.5
9. Over looper
S20422−001
A
S20421−001
L
S20422−001
A
S20424−001 (3,4,5)
B S20428−001
(6,7) C
S20423−001
(3,4,5) M
S20421−001
(6,7) L
S20424−001
B
