Brother GT-341 - 4-4. Platen and T-shirt Handling

GT-3 Series
4. Printing Directly from Applications
89
4-4. Uninstalling / Installing the Platen
Replace the Platen for your print material. When the option Platen e.g. Youth Platen is used, be sure to set
"Platen Size" in Printer Driver menu (see "4-3-3. Selecting the Platen Size").
4-4-1. Uninstalling the Platen
(1) Press the Platen Button to eject the Platen.
(2) Set the Platen Height Adjustment Lever at the "A" position.
(3) Loosen the Platen Fixing Lever underneath the Platen by 1 to 1.5 turns.
(4) Uninstall the Platen by lifting it up straight.
Platen Fixing Lever
