1. FRAME / DRIVE UNIT
REF.NO.
CODE Q'TY DESCRIPTION SYMBOL REMARK
1 LE1744001 1 MAIN MOTOR ASSY/E
2 087320616 4 TAPTITE, CUP S M3X6
3 LJ5701001 1 SOLENOID ASSY/E
4 000300415 1 SCREW, BIND M3X4
5 LJ4432001 4 TAPE 32X12
6 UL8984001 1 LINK
7 LJ4745001 1 FAN MOTOR UNIT B512048-3
8 LJ5704001 1 TONER EMPTY LED PCB UNIT E (Light emission) B512038-4
9 UK4405001 1 PANEL PCB ASSY
10 087320616 3 TAPTITE, CUP S M3X6
11 LJ7403001 4 RUBBER FOOT
12 UL9104001 1 TONER EMPTY PCB UNIT (Light reception) B512037-2
13 087320616 1 TAPTITE, CUP S M3X6
14 LJ8031001 1 LT RELAY PCB ASSY (HL-1450/1470N) B512060-1
15 087320616 1 TAPTITE, CUP S M3X6
16 LE1169001 1 USB GROUND PLATE (HL-1440 Europe)
17 LJ5703001 1 SOLENOID RELEASE SPRING/E
18 LJ5591001 1 PLANET GEAR ASSY (SP)
19 UL8985001 1 GEAR 59
20 LJ5705001 1 GEAR 21 PRESSURE PLATE
21 087320616 1 TAPTITE, CUP S M3X6
22 UL8972001 1 P/R CLUTCH LEVER
23 UL8971001 1 F/R CLUTCH LEVER
24 UL8982001 1 DEVELOP JOINT
25 UL8983001 1 JOINT SPRING
26 LJ7157001 1 FRONT SHIELD FILM
27 LJ7158001 1 REAR SHIELD FILM
28 LJ7159001 1 CENTER SHIELD FILM
29 UL8959001 1 FRICTION SPRING delete
30 LJ5838001 1 PLANET GEAR ASSY B (SP) Ref.No.CHG
MODEL HL-1230/1440/1450/1470N/1430/1435 84U-Z31/Z32/Z33/Z34/Z36-010
T/I NO. PR2002013 / PR2002035 / PR2002071 / PR2002098 / PR2002139 / PR2002157
2. LASER UNIT
REF.NO.
CODE Q'TY DESCRIPTION SYMBOL REMARK
1 LJ5828001 1 LASER UNIT E (SP)
2 087321615 3 TAPTITE, CUP S M3X16
MODEL HL-1230/1440/1450/1470N/1430/1435 84U-Z31/Z32/Z33/Z34/Z36-020
- 1 -
