Confidential
3-31
8.8 MP Cover ASSY/ MP Paper Guide ASSY
(1) Open the MP cover ASSY.
Fig. 3-18
(2) Release the two Bosses of the MP paper guide ASSY.
Fig. 3-19
MP paper guide ASSY
MP cover ASSY
MP paper guide ASSY
Boss
Boss
MP cover ASSY
<Front side>
<Front side>
