1.2 List of Maintenance-mode Functions
* The functions shaded in the table above are user-accessible.
Function
code
Function Refer to:
01 EEPROM parameter initialization 1.3.1 (5-4)
09 Monochrome image quality test pattern 1.3.2 (5-5)
10 Worker switch (WSW) setting 1.3.3 (5-6)
11 Printout of worker switch (WSW) data 1.3.3 (5-6)
12 Operational check of LCD 1.3.4 (5-8)
13 Operational check of control panel key 1.3.5 (5-10)
25 Software version check 1.3.6 (5-11)
28 “One Push Demo” setting 1.3.7 (5-12)
32 Operational check of sensors 1.3.8 (5-13)
33 LAN connection status display 1.3.9 (5-17)
40 EEPROM Dump Print 1.3.10 (5-18)
41 Backup of machine information 1.3.11 (5-19)
45 Changing return value of USB No./Switching Dither Pattern/
Switching of ON/OFF of DirectPrint Color mode-Improve
Gray Color/Switching of timing to execute Auto Registration/
Adjusting left-end print start position on second side in
duplex printing/Change of the transfer current setting/
Change of ghost reduction setting
1.3.12 (5-22)
57 Motor reset 1.3.13 (5-29)
61 Adjustment of touch panel 1.3.14 (5-30)
66 Adjustment of color registration
(Adjustment of inter-color position alignment)
1.3.15 (5-31)
67 Continuous print test 1.3.16 (5-35)
68 Laser unit test pattern print 1.3.17 (5-39)
69 Frame pattern print (One-sided) 1.3.18 (5-40)
70 Frame pattern print (Two-sided) 1.3.19 (5-41)
71 Color test pattern 1.3.20 (5-42)
72 Sensitivity adjustment of density sensor 1.3.21 (5-45)
73 Continuous adjustments of density and registration sensor 1.3.22 (5-46)
74 Setting by country 1.3.23 (5-47)
77 Printout of maintenance information 1.3.24 (5-49)
78 Operational check of fans 1.3.25 (5-51)
80 Display of device log information 1.3.26 (5-52)
82 Display of device error codes 1.3.27 (5-56)
83 Developing bias voltage correction 1.3.28 (5-57)
88 Reset counters for parts 1.3.29 (5-58)
91 EEPROM parameter initialization 1.3.1 (5-4)
99 Exit from the maintenance mode 1.3.30 (5-58)
