Brother MFC-L6900DW

To Next Page

To Previous Page

3-42

Confidential

(9) Remove the six taptite bind B M4x12 screws. Release each hook to remove the

ADF/document scanner unit.

Fig. 3-32

Taptite bind B M4x12

ADF/document scanner unit

Hook

Hooks
