T-8421C, 8422C, 8452C, 8722C, 8752C
4. PREPARATION BEFORE SEWING
24
Specifications indicated by the * mark include arm thread guide D (4) and felt (5). When using polyester thread, install
these components and thread the thread as shown in the illustration.
Do not pass the
thread through.
<For all models except foundation
specifications and T-8452C-405>
Pass the thread
through.
<For foundation specifications
and T-8452C-405>
Cente
(Refer to p.54)
If the tension discs are opened as
follows, the thread will become easier
to thread.
<Models with thread trimmer>
Press the tension release plate (2).
<Models without thread trimmer>
Press the tension release plate (2),
or operate the lifting lever or the knee
lifter to raise the presser foot.
The thread can be passed securely
in between the tension discs.
Pass the thread on the inside of the tab (3).
2183B
To Next Page
