T-8421C, 8422C, 8452C, 8722C, 8752C
14. TROUBLESHOOTING
77
Problem Possible cause Page
5 Uneven seam y Is the presser foot pressure too weak?
Adjust the presser foot pressure.
y Is the feed dog too low?
Adjust the feed dog height.
y Is the bobbin scratched?
If the bobbin is damaged, smooth it with an oiled grindstone or
replace it.
52
73*
6 Large degree of puckering
(excess tension)
y Is the upper thread tension too strong?
Make the upper thread tension as weak as possible.
y Is the lower thread tension too strong?
Make the lower thread tension as weak as possible.
y Are the thread take-up spring tensions too strong?
Make the thread take-up spring tension as weak as possible.
y Is the thread take-up spring operating range too large?
Move the stopper to as high a position as possible.
y Is the presser foot pressure too strong?
Adjust the presser foot pressure.
y Is the sewing speed too fast?
Use the sewing speed control keys to gradually reduce the
sewing speed.
y Is the thread take-up amount too small?
Adjust the thread take-up amount.
51
51
66*
65*
52
28
54
7 Material slippage y Is the presser foot pressure too strong?
Adjust the presser foot pressure.
52
8 Lower thread is tangled at
the sewing start.
Spinning of bobbin during
thread trimming
y Is the bobbin spinning direction correct when the lower thread is
being pulled?
Set the bobbin so that it turns in the opposite direction to the
rotary hook.
y Is there too much thread
wound onto the bobbin?
The bobbin winding
amount should not be
more that 80 %.
y Is
the anti-spin spring attached? (Models with thread trimmer)
Attach the anti-spin spring.
y Is the bobbin turning smoothly?
If the bobbin is not turning smoothly, replace the bobbin.
y Is a bobbin other that the light-alloy bobbins specified by Brother
being used?
Use only bobbins which are specified by Brother.
21
• 22
20
21
• 22
21
• 22
2948M
2949M
2950M
2951M
2124M
Lower
hr
To Next Page
