Chapter 3 Preparation Function TC-32B
2004/01/22 3 - 4 eTCOMNCPR3.doc
3
Group G cord Contents Modal
G00* Positioning
G01 Linear interpolation
G02 Circular/ helical interpolation (CW)
G03 Circular / helical interpolation (CCW)
G102 XZ Circular interpolation (CW)
G103 XZ Circular interpolation (CCW)
G202 YZ Circular interpolation (CW)
G203 YZ Circular interpolation (CCW)
Modal
G04 Dwell One-shot
G09 Exact stop check One-shot
G10 Programmable data input One-shot
G13 Circular cutting CCW One-shot
G17* XY plane selection
G18 YZ plane selection
G19 ZX plane selection
Modal
G22* Programmable stroke limit on
G23 Programmable stroke limit cancel
Modal
G28 Return to the reference point
G29 Return from the reference point
G30 Return to the 2
nd
/3
rd
/4
th
reference point
One-shot
G31 Skip function One-shot
G36 Coordinate calculation function (Bolt hole circle)
G37 Coordinate calculation function (Line-angle)
G38 Coordinate calculation function (Line-angle)
G39 Coordinate calculation function (Grid)
One-shot
G40* Tool dia offset cancel
G41 Tool dia offset left
G42 Tool dia offset right
Modal
The G codes with * mark indicates the modal status when the power is turned ON.
(Note1) Details of coordinate calculation functions are described in " Chapter 6 ".
(Note2) Details of tool dia offset are described in " Chapter 4 ".
