Assembled View:
Attached Chair Leg(C) to Seat Back(A) with
Bolt(H1), Spring Washer(H3) and Flat
washer(H4),tighten the bolts on Footrest to 100%
depth at first, then tighthen the Bolts on Rotary Plate
to 100% depth with Wrench(HW) at last.
12x 12x
12x
1x
67(3
8/9
To Next Page
