120
2. Pull the hood forward.
IInnssttaalllliinngg tthhee HHoooodd
1. The installation is the reverse of removal procedure. However, pay
attention to the following.
TTIIGGHHTTEENNIINNGG TTOORRQQUUEE
Hood Torx screw
2.5 ± 0.2 Nm (22 ± 2 lbf-in)
UUppppeerr BBooddyy MMoodduullee
RReemmoovviinngg tthhee UUppppeerr BBooddyy MMoodduullee
1. Remove:
– Windshield
– Hood
– Side panels
2. Open the storage compartment.
BODY AND SEAT
