127
NNOOTTIICCEE
MMaakkee ssuurree ttoo ppllaaccee ppaanneell iinn aa ssaaffee ppllaaccee ttoo aavvooiidd ssccrraattcchhiinngg..
IInnssttaalllliinngg tthhee SSiiddee PPaanneellss
The installation is the reverse of the removal procedure.
SSeeaatt
SSeeaatt -- 440000 mmmm ((1166 iinn..)) TTuunnnneell WWiiddtthh
RReemmoovviinngg tthhee SSeeaatt ((ttaabb lloocckk))
From between the fuel tank and the seat front end, pull the locking tab
upwards.
Slide the seat backwards while holding the tab up.
BODY AND SEAT
