235
ttiigghhtteenniinngg TToorrqquuee
Check plug 6 ± 1 Nm (53 ± 9 lbf-in)
Filler plug 8 ± 1 Nm (71 ± 9 lbf-in)
GGeeaarrbbooxx OOiill RReeppllaacceemmeenntt
GGeeaarrbbooxx OOiill DDrraaiinniinngg
1. Place the vehicle on a level surface.
2. Place a drain pan under gearbox drain plug area.
3. Remove filler cap.
4. Remove the drain plug located at the bottom of gearbox.
1. Drain plug access hole
5. Wait a while to allow all oil to drain out of gearbox.
6. Install drain plug and tighten to specification.
ttiigghhtteenniinngg ttoorrqquuee
Gearbox drain plug 6 ± 1 Nm (53 ± 9 lbf-in)
GGeeaarrbbooxx OOiill FFiilllliinngg
NNOOTTEE::
Vehicle must be on a level surface.
MAINTENANCE PROCEDURES
To Next Page
