TTYYPPIICCAALL
1. Deflection O-ring aligned with slider shoe
7. Read load recorded by the upper O-ring on the tensiometer.
TTYYPPIICCAALL -- LLOOAADD RREEAADDIINNGG
1. Upper O-ring
8. Load reading must be as per the track deflection in the
Technical
Specifications
.
9. If load reading is not in accordance with the specification, adjust
track tension. Refer to
Track tension adjustment
.
TTrraacckk TTeennssiioonn AAddjjuussttmmeenntt
1. Remove the tether cord cap from engine cut-off switch.
2. Lift rear of vehicle and support it off the ground.
CCAAUUTTIIOONN
UUssee pprrooppeerr lliiffttiinngg tteecchhnniiqquueess,, nnoottaabbllyy uussiinngg yyoouurr lleeggss ffoorrccee.. DDoo
nnoott aatttteemmpptt ttoo lliifftt tthhee rreeaarr ooff vveehhiiccllee iiff iitt iiss aabboovvee yyoouurr lliimmiittss..
MAINTENANCE PROCEDURES
