TTiigghhtteenniinngg ttoorrqquuee
Battery terminals (positive and
negative)
10 ± 2 Nm (89 ± 18 lbf-in)
Battery hold down bracket 5 ± 0.5 Nm (44 ± 4 lbf-in)
Battery cover retaining screws 1.5 ± 0.5 Nm (13 ± 4 lbf-in)
2200”” aanndd 2244”” wwiiddee TTuunnnneell
RReemmoovviinngg tthhee BBaatttteerryy
1. Remove the passenger seat and backrest, if equipped.
2. Open the cargo box, remove the battery cover and all mounting
screws.
LLHH SSIIDDEE SSCCRREEWW SSHHOOWWNN
3. Remove the cargo box.
