INSTALLATION MANUAL
Connection: Inner diameter 25 mm (0.98 in).
Expansion tank
connection
Interface Parameter
Min. Max.
Slip on length 18 mm (0.71 in.)
Figure 8.4: Expansion tank connection
75–00–00
Page 6
December 01 2023
Effectivity: 916 i A / C24
Edition 0/Rev. 1
