BRP-Rotax
INSTALLATION MANUAL
Connector: HIC Connector B (included in the engine’s scope of delivery).
The HIC Connectors must be mounted according to the procedure prescribed in Chapter
76-00-00.
The Display CAN is based on the CAN Aerospace protocol. For detailed interface descrip-
tion contact an authorized ROTAX® Distributor or its independent Service Center.
Electromagnetic
shielding of CAN
Bus
The electromagnetic CAN Bus shielding ring terminals need to be connected with the Air-
frame Ground.
Connector: Ring Terminal M6
77–00–00
Page 8
December 01 2023
Effectivity: 916 i A / C24
Edition 0/Rev. 1
