18
TTRRAAIILLEERR SSEETT--UUPP
Do not change the position of the axle.
The winch support has been adjusted
to fit the watercraft it was purchased
with.
The bunks are fixed to suit the shape
of the watercraft hull. They can not be
adjusted.
TToonngguuee WWeeiigghhtt
If heavy accessories are added or re-
moved from the pontoon, the winch
support position may need to be
readjusted.
Move the winch support towards the
front or rear to move the watercraft
mass. This changes the weight ap-
plied to the tongue.
The tongue weight should be from 7 to
12% of the total trailer and watercraft
weight with tongue parallel to the
ground.
To adjust, loosen the 4 nuts under-
neath the winch support U-bolts,
move winch support to the desired
position.
Tighten nuts to specified torque.
TTiigghhtteenniinngg TToorrqquuee
Winch support
U-bolt nuts
27 ± 3 Nm
(20 ± 2 lbf-ft)
