SAFETY INFORMATION 125
CClliicckkeerr AAddjjuussttmmeenntt LLaabbeell
1. Remove tether cord.
2. Remove pulley expander from pulley guard.
3. Loosen bolt.
4. Adjust clicker.
5. Torque bolt.
5
4
2
1
3
5
( 7 @ 9 Nm )
( 62 @ 80 lb in )
1 2
4
CCLLIICCKKEERR AADDJJUUSSTTMMEENNTT LLAABBEELL
TTYYPPIICCAALL
IMPORTANT ON-PRODUCT LABELS (ALL COUNTRIES EXCEPT CANADA/
UNITED STATES)
