Bryan Boilers Heat Exchanger Type Pool Heater User Manual

Bryan Heat Exchanger Type Pool Heater
Form No. 2000 ©2004 Bryan Steam LLC Printed in USA
44-5952
Bryan Steam LLC — Leaders Since 1916
783 N. Chili Ave., Peru, Indiana 46970 U.S.A.
Phone: 765-473-6651 • Internet: www.bryanboilers.com
Fax: 765-473-3074
• E-mail: bryanboilers@iquest.net
Heater
Model
Heater Rating
Output — BTU's per hr.
Heat Source
Water Temp. Steam Pressure
180°
210°
2# 10#
SH-16-15P 200,000 280,000 400,000 480,000 B2-16-15 20 (50.8) 11 (27.94) 2 (5.08) 2 (5.08) 1½ (3.81) 19 30°F H-41 1 (2.54) 1/6
SH-16-32P 400,000 560,000 800,000 960,000 B2-16-32 37 (93.98) 11 (27.94) 2½ (6.35) 2 (5.08) 2 (5.08) 37 30°F S-35 2 (5.08) 1/6
SH-24-32P 600,000 840,000 1,200,000 1,440,000 B2-24-32 37 (93.98) 11 (27.94) 2½ (6.35) 2 (5.08) 2½ (6.35) 56 30°F S-45 2½ (6.35) 1/4
SH-24-42P 800,000 1,120,000 1,600,000 1,920,000 B2-24-42 47 (119.32) 11 (27.94) 2½ (6.35) 2 (5.08) 3 (7.62) 75 30°F S-46 3 (7.62) 1/3
SH-24-54P 1,000,000 1,400,000 2,000,000 2,400,000 B2-24-54 59 (149.86) 11 (27.94) 2½ (6.35) 2 (5.08) 3 (7.62) 94 30°F S-55 3 (7.62) 1/2
SH-40-48P 1,500,000 2,100,000 3,000,000 3,600,000 D2-40-51 56 (142.24) 13 (33.02) 3 (7.62) 2½ (6.35) 3 (7.62) 141 30°F TV2g 3 (7.62) 1
SH-40-63P 2,000,000 2,800,000 — — D2-40-64 69 (175.26) 13 (33.02) 3 (7.62) 2½ (6.35) — 187 30°F TV2g 3 (7.62) 1
SH-40-77P 2,500,000 3,500,000 — — D2-40-78 83 (210.82) 13 (33.02) 3 (7.62) 2½ (6.35) — 234 30°F TV2g 3 (7.62) 1½
SH-40-99P 3,000,000 4,200,000 — — D2-40-99 105 (266.7) 13 (33.02) 3 (7.62) 2½ (6.35) — 281 30°F TV2g 5 (12.7) 2
Standard
Coil
Model
Dimensions in. (cm) Circulator
A
BC D
E
Length
Diameter
Shell
Tappings
Pool
Water
Tappings
Steam
Valve-IPS
(Pg.1, note 1)
Max.
Flow
GPM
Thru
Shell
Shell
∆∆
∆∆
∆ T
Circ.
Model
Motor
HP
C
A
1" Relief Valve Coupling
B
C
Side View
Support
Bracket
Front View
D
Pool
Temperature
Control
Aquastat
To
Pool
From
Pool
Return Water
Steel Shell
125 PSI ASME
Hot Water From
Central Heating
System
Water Heat Source
Copper Heat Exchanger
F — Heat Source
Circulating Pump To Condensate Main
Steam Trap
Steel Shell
125 PSI ASME
Steam Strainer
E — Steam Control Valve
Copper Heat Exchanger
Steam Heat Source
From
Pool
To
Pool
Steam
Supply
Pool
Temperature
Control
Aquastat
F
Size
in. (cm)
(Pg.1, note 2)
