Bryant 113A Installation Instructions

5
Table 2 – Rating Plate (required) Subcooling Temperatures
Measure
Liquid Pressure
(psig)
R --- 410A Required Liquid Line Temperature _F(_C)
_F (_C) _F (_C) _F (_C) _F (_C) _F (_C) _F (_C)
6 3 8 4 10 6 12 7 14 8 16 9
251 78 26 76 24 74 23 72 22 70 21 68 20
259 80 27 78 26 76 24 74 23 72 22 70 21
266 82 28 80 27 78 26 76 24 74 23 72 22
274 84 29 82 28 80 27 78 26 76 24 74 23
283 86 30 84 29 82 28 80 27 78 26 76 24
291 88 31 86 30 84 29 82 28 80 27 78 26
299 90 32 88 31 86 30 84 29 82 28 80 27
308 92 33 90 32 88 31 86 30 84 29 82 28
317 94 34 92 33 90 32 88 31 86 30 84 29
326 96 36 94 34 92 33 90 32 88 31 86 30
335 98 37 96 36 94 34 92 33 90 32 88 31
345 100 38 98 37 96 36 94 34 92 33 90 32
364 104 40 102 39 100 38 98 37 96 36 94 34
374 106 41 104 40 102 39 100 38 98 37 96 36
384 108 42 106 41 104 40 102 39 100 38 98 37
395 110 43 108 42 106 41 104 40 102 39 100 38
406 112 44 110 43 108 42 106 41 104 40 102 39
416 114 46 112 44 110 43 108 42 106 41 104 40
427 116 47 114 46 112 44 110 43 108 42 106 41
439 118 48 116 47 114 46 112 44 110 43 108 42
450 120 49 118 48 116 47 114 46 112 44 110 43
462 122 50 120 49 118 48 116 47 114 46 112 44
474 124 51 122 50 120 49 118 48 116 47 114 46
Table 3 – Superheat Charging -- AC Only
OUTDOOR TEMP (_F)
EVAPORATOR ENTERING AIR TEMPERATURE (_FWB)
50 52 54 56 58 60 62 64 67 68 70 72 74 76
55 9 12 14 17 20 23 26 29 32 35 37 40 42 45
60 7 10 12 15 18 21 24 27 30 33 35 38 40 43
65 — 6 10 13 16 19 21 24 27 30 33 36 38 41
70 — — 7 10 13 16 19 21 24 27 30 33 36 39
75 — — — 6 9 12 15 18 21 24 28 31 34 37
80 — — — — 5 8 12 15 18 21 25 28 31 35
85 — — — — — — 8 11 15 19 22 26 30 33
90 — — — — — — 5 9 13 16 20 24 27 31
95 — — — — — — — 6 10 14 18 22 25 29
100 — — — — — — — — 8 12 15 20 23 27
105 — — — — — — — — 5 9 13 17 22 26
110 — — — — — — — — — 6 11 15 20 25
115 — — — — — — — — — — 8 14 18 23
*Optimum performance point, 95_F(35_C) outdoor ambient and (80_F/27_C dry bulb), (67_F/19_C wet bulb) indoor conditions. (DOE A Test Conditions)
Where a dash (--- --- ) appears do not attempt to charge system under these conditions or refrigerant slugging may occur. Charge must be weighed in.
Note: Superheat _F is at low --- side service port, Allow a tolerance of ±3_F(±1.7_C)
Note: Indoo r dry bulb between 70_Fand80_F(21_Cand27_C)
113A / 116B
