Bryant 550A User Manual

—4—
SPECIFICATIONS
See notes on page 5.
.
UNIT SIZE-SERIES 024-G 030-F 036-F/G
Operating Weight (Lb) 214 202 237
ELECTRICAL
Unit Volts—Hertz—Phase 208/230—60—1
Operating Voltage Range* 187—253
Compressor— Rated Load Amps 12.8 14.7 15.4/16.7
Locked Rotor Amps 60.0 72.5 83.0/79.0
Condenser Fan Motor—Full Load Amps 0.80 0.80 1.1
Min Unit Ampacity for Wire Sizing 16.8 19.2 20.2/22.0
Min Wire Size (60°C Copper) AWG† 14 14 12
Min Wire Size (75°C Copper) AWG† 14 14 12
Max Wire Length (Ft) (60°C Copper)‡ 46 41 62/57
Max Wire Length (Ft) (75°C Copper)‡ 44 39 59/54
Max Branch Circuit Fuse or
Circuit Breaker Size (Amps) 25 30 30
COMPRESSOR & REFRIGERANT
Compressor— Type Scroll
Temperature & Current Protection Internal Line Break
Refrigerant— Type Puron® (R-410A)
Amount (Lb) 5.50 6.00 6.88
CONDENSER COIL & FAN
Coil Face Area (Sq Ft) 12.2 12.2 15.2
Fins per In.—Rows—Circuits 25—1—2 25—1—2 25—1—2
Fan Motor—HP (PSC) & RPM 1/8 & 825 1/8 & 825 1/5 & 825
Volts—Hertz—Phase 208/230—60—1
Condenser Airflow (CFM) 2400 2400 2800
OPTIONAL EQUIPMENT
Support Feet KSASF0101AAA
Coastal Filter KAACF0801MED
Time Delay Relay KAATD0101TDR
Cycle Protector KSACY0101AAA
Crankcase Heater KAACH1201AAA
Start Assist—Capacitor/Relay Type KSAHS1501AAA
Start Assist—PTC Type Standard KAACS0201PTC
TXV (Hard Shutoff) KSATX0201PUR KSATX0301PUR
Piston Body KSAPX0101PIS
Filter Drier (Suction Line) KH45LG140 (RCD)
Evaporator Freeze Thermostat** KAAFT0101AAA
Liquid-Line Solenoid Valve KAALS0201LLS
Winter Start Control** KAAWS0101AAA
Low-Ambient Pressure Switch KSALA0301410
MotorMaster® Low-Ambient Controller †† KSALA0401AAA
Ball Bearing Fan Motor HC38GE231 (RCD)
Thermidistat™ Control—
Programmable Thermostat with Humidity Control TSTATBBPRH01-B
Thermostat—Auto Changeover,
7-Day Programmable, °F/°C,
1-Stage Heat, 1-Stage Cool TSTATBBPAC01-B
Thermostat—Auto Changeover,
Non-Programmable, °F/°C,
1-Stage Heat, 1-Stage Cool TSTATBBNAC01-C
Thermostat—Manual Changeover
5-2 Day Programmable, °F/°C,
1-Stage Heat, 1-Stage Cool TSTATBBSAC01
Builder’s Thermostat—Manual Changeover,
Non-Programmable, °F/°C,
1-Stage Heat, 1-Stage Cool TSTATBBBAC01-B
Outdoor Air Temperature Sensor TSTATXXSEN01-B
Backplate for Non-Programmable Thermostat TSTATXXNBP01
Backplate for Programmable Thermostat TSTATXXPBP01
Backplate for Builder’s Thermostat TSTATXXBBP01
Backplate for Standard Thermostat TSTATXXSBP01
Thermostat Conversion Kit (4 to 5 wire)—10 Pack TSTATXXCNV10
Evolution Controls See chart.
