Table 8 — Accessory/FIOP Static Pressure (in. wg) — 559F180
COMPONENT
CFM
4500 5000 6000 7200 7500
Economizer 0.04 0.05 0.07 0.09 0.10
Glycol Coil 0.22 0.26 0.35 0.44 0.46
Electric Heat (kW)
26/34 0.06 0.07 0.09 0.11 0.12
32 0.06 0.07 0.09 0.11 0.12
42/56 0.07 0.08 0.12 0.16 0.17
55 0.07 0.08 0.12 0.15 0.17
56/75 0.09 0.10 0.15 0.20 0.21
80 0.09 0.10 0.15 0.20 0.21
LEGEND
FIOP — Factory-Installed Option
NOTES:
1. The static pressure must be added to external static pressure. The
sum and the evaporator entering-air cfm should then be used in con-
junction with the Fan Performance tables to determine blower rpm
and watts.
2. Heaters are rated at 208/240 v and 480 v.
Table 9 — Accessory/FIOP Static Pressure (in. wg) — 559F216-300
COMPONENT
CFM
5400 6000 7200 9000 10,000 11,250
Economizer 0.06 0.07 0.09 0.11 0.12 0.14
Glycol Coil 0.30 0.35 0.44 0.58 0.66 0.77
Electric Heat (kW)
26/34 0.08 0.09 0.11 0.15 0.17 0.20
32 0.08 0.09 0.11 0.15 0.17 0.20
42/56 0.11 0.12 0.15 0.19 0.21 0.24
55 0.11 0.12 0.15 0.19 0.21 0.24
56/75 0.14 0.15 0.20 0.24 0.26 0.29
80 0.14 0.15 0.20 0.24 0.26 0.29
LEGEND
FIOP — Factory-Installed Option
NOTES:
1. The static pressure must be added to external static pressure. The
sum and the evaporator entering-air cfm should then be used in con-
junction with the Fan Performance tables to determine blower rpm
and watts.
2, Heaters are rated at 208/240 v and 480 v.
Table 10 — Fan Rpm at Motor Pulley Settings*
UNIT
559F
MOTOR PULLEY TURNS OPEN
0
1
⁄ 2 11
1
⁄ 2 22
1
⁄ 2 33
1
⁄ 2 44
1
⁄ 2 55
1
⁄ 2 6
180† †† †† 1179 1150 1121 1093 1064 1035 1006 978 949 920 891
180** †† †† 1559 1522 1488 1455 1422 1389 1356 1323 1289 1256 1227
216† †† †† 1095 1077 1058 1040 1021 1002 984 965 947 928 910
216** †† †† 1287 1265 1243 1222 1200 1178 1156 1134 1112 1091 1069
240† †† †† 1225 1209 1187 1165 1143 1120 1098 1076 1053 1031 1002
240** †† †† 1458 1434 1407 1381 1354 1328 1301 1275 1248 1222 1193
300† †† †† 1283 1269 1247 1225 1203 1182 1160 1138 1116 1095 1066
300** †† †† — — 1551 1524 1497 1470 1443 1415 1388 1361 1332
*Approximate fan rpm shown.
†Indicates standard drive package.
**Indicates alternate drive package.
††Due to belt and pulley size, pulley cannot be set to this number of turns open.
NOTE: For speeds not listed above, field-supplied drives are required.
—19—
