Table 1B — Specifications (SI)
UNIT 569C072 569C090 569C120 576B090 576B102 576B120
NOMINAL CAPACITY (kW) 21 26 35 26 29.9 35
OPERATING WEIGHT (kg)
Aluminum Coils (Standard) 154 168 179 231 256 256
Copper Coils (Optional) 175 199 214 262 287 287
RIGGING WEIGHT (kg)
Aluminum Coils (Standard) 176 191 202 254 279 279
Copper Coils (Optional) 198 221 237 285 309 309
REFRIGERANT* R-22
COMPRESSOR Bristol, Reciprocating Copeland, Scroll Copeland, Scroll Reciprocating, Semi-Hermetic
Quantity...Type 1...H26A72Q 1...ZR94KC 1...ZR125KC 1...06DA818 1...06DA824
1...06DH824
(See Note 1)
Quantity Cylinders 2——4 6
Speed (R/s) 58.4 58.4 58.4 29.2 29.2
Oil Charge (L) (ea) 1.92 2.51 3.25 2.60 3.78
CONDENSER FAN Propeller; Direct Drive
Quantity...R/s 1...14.2 1...18.3
Diameter (mm) 660 660
Motor Hp (NEMA)
1
⁄
3
3
⁄
4
Nominal Airflow (L/s) 1800 3050 3300 3050 3050 3050
CONDENSER COIL Enhanced Copper Tubes, Aluminum Lanced Fins
Face Area (sq m) 1.14 1.46 1.90 1.67 1.67 1.67
Storage Capacity (kg)† 5.1 6.75 8.6 7.5 7.5 7.5
CONNECTIONS (sweat)
Suction (in.) 1
1
⁄
8
1
1
⁄
8
1
1
⁄
8
1
1
⁄
8
1
1
⁄
8
1
1
⁄
8
Liquid (in.)
1
⁄
2
1
⁄
2
5
⁄
8
1
⁄
2
5
⁄
8
5
⁄
8
CONTROLS
Pressurestat Settings (kPa)
High Cutout 2937 6 48
Cut-in 2206 6 138
Low Cutout 48 6 20
Cut-in 152 6 34
LEGEND
NEMA — National Electrical Manufacturing Association
*Unit is factory supplied with holding charge only.
†Storage capacity of condenser coil with coil 80% full of liquid R-22 at
51 C.
NOTES:
1. Unit 576B120 has one step of unloading. Full load is 100% capacity,
and one step of unloading is 67% capacity. Unit 576B120 has the
following unloader settings: load is 483 6 6.9 kPa and unload is
414 6 13.8 kPa.
2. Equivalent mm values for connectors are as follows:
in. mm
1
⁄
2
12.7
5
⁄
8
15.9
1
1
⁄
8
28.6
—4—
