Table 10 — Dry Coil Air Delivery* — Horizontal and Downflow Discharge —
Unit 583A024-060 (Deduct 10% for 208 Volts)
230 AND 460 VOLT
Unit
583A
Motor
Speed
External Static Pressure (in. wg)
0.00 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
024
Low
Watts 281282281278276— —————
Cfm 899828757691619— —————
Med
Watts — — — 375 370 363 357 352 — — —
Cfm — — — 969 897 824 744 649 — — —
High
Watts —————468457444431423—
Cfm —————994913826730620—
030
Low
Watts 246244243241———————
Cfm 982860808736———————
Med
Watts 343339336332328322317————
Cfm 1233 1170 1109 1038 953 855 754 ————
High
Watts ————441432421410400——
Cfm ————1202 1111 1021 929 826 — —
036
Low
Watts — 470 458 445 430 415 399 384 — — —
Cfm — 1463 1406 1344 1273 1188 1091 983 — — —
Med
Watts — — 514 501 487 471 455 438 422 — —
Cfm — — 1497 1428 1348 1255 1152 1042 929 — —
High
Watts — — — 646 636 626 614 602 589 — —
Cfm — — — 1491 1412 1325 1228 1120 1003 — —
042
Low
Watts 643 625 614 605 593 574 549 518 485 454 —
Cfm 1626 1614 1579 1532 1478 1421 1361 1295 1218 1120 —
Med
Watts ————726695661625591561540
Cfm ————1731 1672 1610 1541 1456 1345 1193
High
Watts ———————790766742713
Cfm ———————1699 1602 1494 1367
048
Low
Watts 614 588 577 572 566 556 539 517 491 — —
Cfm 1591 1549 1518 1490 1460 1421 1372 1312 1242 — —
Med
Watts 778 756 738 719 699 676 650 623 596 572 555
Cfm 1854 1837 1804 1759 1705 1643 1577 1508 1440 1375 1315
High
Watts ————896862829800775752728
Cfm ————1956 1879 1797 1709 1615 1514 1406
060
Low
Watts 834 813 782 746 712 680 652 626 — — —
Cfm 2016 1955 1898 1840 1781 1717 1646 1566 — — —
Med
Watts 941 889 851 822 797 772 745 714 679 639 —
Cfm 2379 2233 2124 2038 1964 1892 1814 1727 1626 1511 —
High
Watts — — 960 949 920 883 845 812 783 753 —
Cfm — — 2497 2224 2075 1986 1915 1831 1721 1588 —
*Air delivery values are without air filter and are for dry coil. (See Table 11B — Wet Coil Pressure Drop
table.)
NOTE: Deduct field-supplied air filter pressure drop and wet coil pressure drop to obtain external static
pressure available for ducting.
—28—
