—23—
CONDENSER ONLY RATINGS* Continued
* ARI listing applies only to systems shown in Ratings and Performance table.
KW — Total Power (Kw)
SDT — Saturated Temperature Leaving Compressor (°F)
SST — Saturated Temperature Entering Compressor (°F)
TCG— Gross Cooling Capacity (1000 Btuh).
SST
°F
CONDENSER ENTERING AIR TEMPERATURES °F
55 65 75 85 95 105 115
597C042-F
30
TCG 38.6 36.8 35.0 33.2 31.4 29.6 27.9
SDT 75.0 84.9 95.0 105.0 115.0 125.0 135.0
KW 2.16 2.42 2.71 3.03 3.39 3.80 4.25
35
TCG 42.7 40.8 38.8 36.9 34.9 33.0 31.1
SDT 75.0 85.0 95.0 105.0 115.0 125.0 135.0
KW 2.15 2.40 2.70 3.02 3.38 3.79 4.24
40
TCG 47.0 45.0 43.0 40.8 38.7 36.6 34.5
SDT 75.2 85.0 95.0 105.0 115.0 125.0 135.0
KW 2.14 2.39 2.68 3.00 3.37 3.77 4.22
45
TCG 51.4 49.3 47.2 45.0 42.7 40.5 38.2
SDT 76.7 86.2 95.8 105.0 115.0 125.0 135.0
KW 2.15 2.40 2.68 3.00 3.36 3.75 4.20
50
TCG 55.9 53.7 51.5 49.2 46.8 44.4 42.0
SDT 78.4 87.8 97.3 107.0 116.0 126.0 136.0
KW 2.18 2.43 2.71 3.03 3.38 3.77 4.21
55
TCG 60.7 58.4 56.0 53.6 51.1 48.5 46.0
SDT 80.3 89.6 99.1 109.0 118.0 128.0 137.0
KW 2.21 2.46 2.75 3.07 3.42 3.81 4.25
597C048-G, F
30
TCG 46.4 44.2 42.0 39.7 37.4 35.0 32.5
SDT 75.4 85.1 95.0 105.0 115.0 125.0 135.0
KW 2.29 2.64 3.03 3.48 3.96 4.48 5.03
35
TCG 50.9 48.6 46.3 43.9 41.5 39.0 36.4
SDT 77.0 86.5 96.1 106.0 115.0 125.0 135.0
KW 2.30 2.65 3.04 3.47 3.95 4.46 5.02
40
TCG 55.6 53.2 50.8 48.2 45.7 43.0 40.3
SDT 78.8 88.3 97.8 107.0 117.0 126.0 136.0
KW 2.33 2.68 3.07 3.51 3.98 4.50 5.05
45
TCG 60.6 58.0 55.4 52.7 50.0 47.2 44.3
SDT 80.8 90.2 99.7 109.0 119.0 128.0 138.0
KW 2.35 2.71 3.11 3.55 4.03 4.55 5.12
50
TCG 65.9 63.1 60.4 57.5 54.6 51.6 48.5
SDT 82.9 92.3 102.0 111.0 121.0 130.0 139.0
KW 2.39 2.75 3.15 3.60 4.09 4.62 5.19
55
TCG 71.4 68.5 65.6 62.5 59.4 56.2 53.0
SDT 85.2 94.5 104.0 113.0 123.0 132.0 141.0
KW 2.42 2.79 3.20 3.65 4.14 4.68 5.27
597C060-F
30
TCG 55.0 52.6 50.2 47.6 45.0 42.4 39.9
SDT 76.1 85.8 95.6 105.0 115.0 125.0 135.0
KW 2.88 3.25 3.66 4.13 4.61 5.08 5.56
35
TCG 60.2 57.7 55.1 52.3 49.6 46.9 44.1
SDT 77.8 87.4 97.1 107.0 116.0 126.0 136.0
KW 2.92 3.29 3.70 4.17 4.65 5.12 5.59
40
TCG 65.6 63.0 60.3 57.3 54.4 51.4 48.5
SDT 79.6 89.2 98.8 108.0 118.0 128.0 137.0
KW 2.96 3.34 3.75 4.23 4.71 5.19 5.67
45
TCG 71.3 68.7 65.8 62.6 59.5 56.4 53.2
SDT 81.5 91.2 101.0 110.0 120.0 129.0 139.0
KW 3.01 3.39 3.82 4.30 4.78 5.27 5.75
50
TCG 77.3 74.5 71.5 68.2 64.8 61.5 58.2
SDT 83.6 93.2 103.0 112.0 122.0 131.0 141.0
KW 3.05 3.45 3.88 4.37 4.86 5.36 5.85
55
TCG 83.6 80.7 77.5 74.0 70.5 67.0 63.5
SDT 85.8 95.4 105.0 114.0 124.0 133.0 143.0
KW 3.11 3.51 3.95 4.45 4.95 5.45 5.96
