35
DETAILED COOLING CAPACITIES# (CONTINUED)
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F (°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ Total Sens‡ To t a l Sens‡ To t a l Sens‡ Tot a l Sens‡ To t a l Sens‡
187BNA048---A HIGH Outdoor Section With CNPHP6124 INDOOR SECTION Indoor Section
1100
57 (13.9) 44.11 44.11 2.98 42.88 42.88 3.26 41.49 41.49 3.57 39.91 39.91 3.91 38.10 38.10 4.27 36.02 36.02 4.68
62 (16.7) 47.19 37.81 3.01 45.48 36.75 3.29 43.59 35.65 3.59 41.47 34.47 3.92 39.11 33.21 4.29 36.46 31.85 4.69
63 (17.2)†† 48.16 31.42 3.01 46.41 30.39 3.30 44.46 29.30 3.60 42.27 28.15 3.93 39.81 26.91 4.29 37.03 25.59 4.70
67 (19.4) 52.08 32.59 3.05 50.18 31.55 3.33 48.05 30.44 3.64 45.65 29.25 3.97 42.99 28.01 4.33 39.98 26.67 4.74
72 (22.2) 57.49 27.28 3.10 55.36 26.24 3.38 52.80 25.07 3.68 50.34 23.98 4.02 47.37 22.74 4.39 44.05 21.42 4.79
1225
57 (13.9) 45.88 45.88 3.06 44.56 44.56 3.35 43.06 43.06 3.66 41.36 41.36 3.99 39.42 39.42 4.36 37.19 37.19 4.77
62 (16.7) 48.28 39.97 3.09 46.49 38.89 3.37 44.50 37.75 3.67 42.31 36.53 4.00 39.87 35.21 4.37 37.22 37.22 4.77
63 (17.2)†† 49.24 32.90 3.09 47.38 31.84 3.37 45.32 30.72 3.68 43.02 29.53 4.01 40.45 28.26 4.37 37.58 26.92 4.77
67 (19.4) 53.21 34.17 3.13 51.18 33.08 3.41 48.95 31.95 3.71 46.45 30.74 4.05 43.65 29.46 4.41 40.53 28.10 4.82
72 (22.2) 58.71 28.28 3.18 56.43 27.20 3.46 53.95 26.08 3.77 51.17 24.89 4.10 48.08 23.63 4.47 44.63 22.29 4.87
1400
57 (13.9) 48.10 48.10 3.15 46.66 46.66 3.43 45.03 45.03 3.74 43.17 43.17 4.07 41.07 41.07 4.44 38.67 38.67 4.85
62 (16.7) 49.64 42.97 3.16 47.76 41.83 3.44 45.70 40.63 3.75 43.44 39.31 4.08 41.13 41.13 4.44 38.72 38.72 4.85
63 (17.2)†† 50.51 34.94 3.17 48.55 33.85 3.45 46.35 32.69 3.75 43.94 31.47 4.08 41.25 30.18 4.44 38.26 28.80 4.85
67 (19.4) 54.55 36.35 3.21 52.38 35.23 3.49 50.03 34.06 3.79 47.39 32.82 4.12 44.47 31.51 4.48 41.22 30.12 4.89
72 (22.2) 60.12 29.67 3.26 57.73 28.57 3.54 55.08 27.41 3.84 52.04 26.15 4.17 48.93 24.90 4.54 45.33 23.53 4.94
1600
57 (13.9) 50.24 50.24 3.24 48.67 48.67 3.52 46.90 46.90 3.83 44.88 44.88 4.16 42.63 42.63 4.53 40.04 40.04 4.94
62 (16.7) 50.97 46.17 3.25 49.03 44.96 3.53 46.92 46.83 3.83 44.95 44.95 4.17 42.68 42.68 4.53 40.09 40.09 4.94
63 (17.2)†† 51.64 37.15 3.25 49.57 36.02 3.53 47.27 34.82 3.83 44.74 33.58 4.16 41.96 32.26 4.52 38.87 30.84 4.93
67 (19.4) 55.73 38.71 3.29 53.45 37.55 3.57 50.96 36.35 3.87 48.22 35.09 4.20 45.18 33.75 4.57 41.84 32.33 4.97
72 (22.2) 61.38 31.16 3.34 58.85 30.03 3.62 56.08 28.84 3.92 53.02 27.59 4.26 49.66 26.28 4.62 45.93 24.89 5.02
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F (°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ Total Sens‡ To t a l Sens‡ To t a l Sens‡ Tot a l Sens‡ To t a l Sens‡
187BNA048---A LOW Outdoor Section With CNPHP6124 INDOOR SECTION Indoor Section
880
57 (13.9) 32.76 32.76 2.04 31.62 31.62 2.30 30.36 30.36 2.59 28.98 28.98 2.91 27.46 27.46 3.28 25.76 25.76 3.70
62 (16.7) 34.58 28.44 2.04 33.05 27.76 2.29 31.40 27.03 2.58 29.61 26.24 2.90 27.69 25.39 3.27 25.81 25.81 3.70
63 (17.2)†† 35.34 23.42 2.03 33.77 22.73 2.29 32.06 22.00 2.57 30.21 21.21 2.90 28.19 20.37 3.27 26.00 19.48 3.70
67 (19.4) 38.47 24.43 2.02 36.75 23.73 2.27 34.90 22.99 2.55 32.88 22.19 2.87 30.69 21.34 3.23 28.30 20.43 3.66
72 (22.2) 42.82 20.36 2.01 40.90 19.65 2.25 38.84 18.90 2.53 36.60 18.09 2.83 34.16 17.23 3.19 31.50 16.31 3.61
1050
57 (13.9) 35.07 35.07 2.06 33.79 33.79 2.32 32.38 32.38 2.60 30.84 30.84 2.91 29.15 29.15 3.28 27.27 27.27 3.70
62 (16.7) 35.99 31.46 2.06 34.36 30.73 2.31 32.63 29.95 2.59 30.89 30.89 2.91 29.19 29.19 3.28 27.31 27.31 3.70
63 (17.2)†† 36.67 25.49 2.06 34.97 24.78 2.31 33.13 24.01 2.59 31.15 23.20 2.91 29.01 22.33 3.28 26.69 21.40 3.71
67 (19.4) 39.88 26.65 2.05 38.02 25.92 2.29 36.02 25.15 2.57 33.87 24.32 2.88 31.54 23.45 3.25 29.01 22.51 3.67
72 (22.2) 44.36 21.79 2.04 42.29 21.05 2.28 40.06 20.27 2.55 37.53 19.39 2.85 35.06 18.54 3.21 32.24 17.59 3.62
1145
57 (13.9) 36.17 36.17 2.07 34.81 34.81 2.32 33.33 33.33 2.60 31.71 31.71 2.92 29.93 29.93 3.28 27.97 27.97 3.70
62 (16.7) 36.66 33.05 2.07 35.02 32.29 2.32 33.39 33.39 2.60 31.77 31.77 2.92 29.98 29.98 3.28 28.01 28.01 3.70
63 (17.2)†† 37.25 26.59 2.07 35.49 25.86 2.32 33.60 25.09 2.60 31.56 24.26 2.92 29.36 23.38 3.29 26.99 22.43 3.72
67 (19.4) 40.49 27.83 2.06 38.57 27.09 2.31 36.51 26.30 2.58 34.29 25.47 2.90 31.90 24.57 3.26 29.32 23.62 3.68
72 (22.2) 45.02 22.54 2.05 42.89 21.79 2.29 40.58 20.99 2.56 38.01 20.11 2.86 35.43 19.24 3.22 32.54 18.28 3.63
1250
57 (13.9) 37.25 37.25 2.09 35.82 35.82 2.34 34.27 34.27 2.61 32.57 32.57 2.93 30.70 30.70 3.29 28.64 28.64 3.71
62 (16.7) 37.39 34.70 2.09 35.88 35.88 2.34 34.32 34.32 2.61 32.62 32.62 2.93 30.75 30.75 3.29 28.68 28.68 3.71
63 (17.2)†† 37.79 27.77 2.09 35.98 27.03 2.34 34.04 26.24 2.62 31.95 25.40 2.94 29.70 24.50 3.30 27.28 23.53 3.73
67 (19.4) 41.06 29.09 2.08 39.08 28.33 2.32 36.97 27.54 2.60 34.69 26.69 2.91 32.24 25.78 3.27 29.61 24.81 3.69
72 (22.2) 45.64 23.33 2.07 43.43 22.57 2.31 41.06 21.76 2.57 38.51 20.90 2.88 35.77 19.99 3.23 32.81 19.01 3.64
187B / 180B
