DETAILED COOLING CAPACITIES# (CONTINUED)
187BNA060---A Outdoor Section With CNPHP6124 Indoor Section
Cooling
Indoor Model
High
Speed
Cap.
Power
Low
Speed
Cap.
Power Furnace Model
*CNPH*6124A** 1.00 1.00 1.00 1.00 313*AV060110
CAP**6021A** 0.99 1.02 0.99 1.12 CAP**6024A** 0.99 1.02 0.99 1.12 CAP**6025A** 0.97 1.06 0.98 1.14
CNPH*6024A** 0.99 1.02 0.99 1.12 CNPH*6124A** 1.00 1.02 1.00 1.12
CNPV*6024A** 0.99 1.02 0.99 1.12 CNPV*6124A** 1.01 1.02 1.01 1.13
CSPH*6012A** 1.00 1.02 1.00 1.12
FE4ANB006 1.01 0.98 1.02 1.00 FV4CNB006 1.01 0.98 1.02 1.00
CAP**6021A** 0.99 0.99 0.99 1.00 313*AV060110
CNPH*6024A** 0.99 0.99 1.00 1.00 313*AV060110
CNPV*6024A** 0.99 0.99 1.01 1.03 313*AV060110 CNPV*6124A** 1.01 0.99 1.03 1.03 313*AV060110
CSPH*6012A** 1.00 0.99 1.00 0.99 313*AV060110
CAP**6024A** 0.99 1.00 0.99 1.00 313*AV060135
CNPH*6024A** 0.99 1.00 1.00 1.01 313*AV060135 CNPH*6124A** 0.99 1.00 1.00 1.01 313*AV060135
CNPV*6024A** 0.99 1.00 1.00 1.01 313*AV060135 CNPV*6124A** 1.00 0.99 1.01 1.00 313*AV060135
CSPH*6012A** 0.99 0.99 1.00 1.00 313*AV060135
CAP**6021A** 0.99 1.01 1.00 1.04 315(A,J)AV060110
CNPH*6024A** 0.99 1.01 1.00 1.03 315(A,J)AV060110 CNPH*6124A** 0.99 1.01 1.01 1.05 315(A,J)AV060110
CNPV*6024A** 0.99 1.01 1.00 1.03 315(A,J)AV060110
Cooling
Indoor Model
High
Speed
Cap.
Power
Low
Speed
Cap.
Power Furnace Model
CNPV*6124A** 1.00 1.00 1.02 1.03 315(A,J)AV060110
CSPH*6012A** 0.99 1.00 1.01 1.03 315(A,J)AV060110
CAP**6024A** 0.99 0.99 1.00 1.02 315(A,J)AV066135
CNPH*6024A** 0.99 0.99 1.00 1.01 315(A,J)AV066135 CNPH*6124A** 1.00 1.00 1.01 1.03 315(A,J)AV066135
CNPV*6024A** 0.99 0.99 1.00 1.01 315(A,J)AV066135 CNPV*6124A** 1.01 0.99 1.02 1.02 315(A,J)AV066135
CSPH*6012A** 1.00 0.99 1.01 1.02 315(A,J)AV066135
CAP**6024A** 1.00 0.99 1.01 1.02 315(A,J)AV066155
CNPH*6024A** 0.99 0.98 1.01 1.01 315(A,J)AV066155 CNPH*6124A** 1.00 0.98 1.01 1.02 315(A,J)AV066155
CNPV*6024A** 0.99 0.98 1.01 1.01 315(A,J)AV066155 CNPV*6124A** 1.01 0.99 1.02 1.01 315(A,J)AV066155
CSPH*6012A** 1.00 0.98 1.01 1.00 315(A,J)AV066155
CAP**6024A** 0.99 1.00 0.99 1.00 353(A,B)AV060100
CNPH*6024A** 0.99 0.99 1.00 1.01 353(A,B)AV060100 CNPH*6124A** 0.99 0.99 1.00 1.01 353(A,B)AV060100
CNPV*6024A** 0.99 0.99 1.00 1.01 353(A,B)AV060100 CNPV*6124A** 1.00 0.99 1.01 1.00 353(A,B)AV060100
CSPH*6012A** 0.99 0.98 1.00 1.00 353(A,B)AV060100
CAP**6024A** 0.99 0.98 1.00 1.00 353(A,B)AV060120
CNPH*6024A** 0.99 0.99 1.00 1.00 353(A,B)AV060120 CNPH*6124A** 0.99 0.98 1.00 1.00 353(A,B)AV060120
CNPV*6024A** 0.99 0.98 1.00 1.00 353(A,B)AV060120 CNPV*6124A** 0.99 0.99 1.00 0.98 353(A,B)AV060120
CAP**6021A** 0.98 1.06 0.99 1.05 355(A,C)AV060080
Cooling
Indoor Model
High
Speed
Cap.
Power
Low
Speed
Cap.
Power Furnace Model
CSPH*6012A** 0.98 1.05 1.00 1.05 355(A,C)AV060080
CAP**6021A** 0.98 1.04 1.00 1.08 355(A,C)AV060100
CNPH*6024A** 0.97 1.03 1.00 1.07 355(A,C)AV060100 CNPH*6124A** 0.98 1.04 1.01 1.09 355(A,C)AV060100
CNPV*6024A** 0.97 1.03 1.00 1.07 355(A,C)AV060100 CNPV*6124A** 0.99 1.03 1.01 1.07 355(A,C)AV060100
CSPH*6012A** 0.98 1.03 1.01 1.08 355(A,C)AV060100
CAP**6024A** 0.98 1.01 1.00 1.05 355(A,C)AV060120
CNPH*6024A** 0.98 1.01 1.00 1.05 355(A,C)AV060120 CNPH*6124A** 0.99 1.02 1.01 1.06 355(A,C)AV060120
CNPV*6024A** 0.98 1.01 1.00 1.05 355(A,C)AV060120 CNPV*6124A** 1.00 1.02 1.01 1.04 355(A,C)AV060120
CSPH*6012A** 0.99 1.01 1.01 1.05 355(A,C)AV060120
CAP**6025A** 0.96 1.07 0.98 1.05 359BAV060080 CAP**6025A** 0.96 1.06 0.99 1.07 359BAV060100 CAP**6025A** 0.96 1.06 0.99 1.04 359BAV060100 CAP**6021A** 0.99 1.03 1.00 1.04 368RAN060120 CAP**6024A** 0.98 1.01 1.00 1.04 368RAN060120
CNPV*6024A** 0.99 1.01 1.00 1.03 368RAN060120 CNPV*6124A** 1.01 1.02 1.01 1.02 368RAN060120
CAP**6021A** 0.97 1.06 1.00 1.06 374RAN060120 CAP**6024A** 0.98 1.05 1.00 1.06 374RAN060120
CNPV*6024A** 0.97 1.04 1.00 1.05 374RAN060120 CNPV*6124A** 1.00 1.04 1.01 1.04 374RAN060120
CSPH*6012A** 0.99 1.04 1.01 1.05 374RAN060120
{ Total and sensible capacities are net capacities. Blower motor heat has been subtracted. } Sensible capacities shown are based on 80_F(27_C) entering air at the indoor coil. For sensible capacities at other than 80_F(27_C), deduct 835 Btuh
(245 kW) per 1000 CFM (480 L/S) of indoor coil air for each degree below 80_F(27_C), or add 835 Btuh (245 kW) per 1000 CFM (480 L/S) of indoor coil air per degree above 80_F(27_C).
# Detailed cooling capacities are based on indoor and outdoor unit at the same elevation per AHRI standard 210/240---94. If additional tubing length and/or indoor unit is located above outdoor unit, a slight variation in capacity may
occur.
* Tested Combination ** System kw is total of indoor and outdoor unit kilowatts. EWB — Entering Wet Bulb NOTE: 1. Multipliers for 355BAV are equal to 355(A,C)AV 2. When the required data fall between the published data, interpolation may be performed. Extrapolation is not an acceptable practice.
